Laird TRBLU23-00200 Bluetooth Intelligent Serial Module, BISM2, Bluetooth 2.0

Laird Connectivity
$9.95

TRBLU23-00200 Bluetooth 2.0 Intelligent Serial Module (BISM2) with integrated antenna manufactured by Laird Connectivity.

Operates on 3.6 V to 7.0 V.

These are individually packaged in factory anti-static bags with a serial number sticker.

Chipset: CSR BC04 (Cambridge Silicon Radio BlueCore 04)

The Hirose DF12C board-to-board connector on the module is a 40-pin double-row receptacle. Mates with a Hirose DF12 series DF12(3.5)-40DP-0.5V(86), DF12(4.0)-40DP-0.5V(86) or DF12(5.0)-40DP-0.5V(86) mating header (NOT INCLUDED).

Please see product photos for Pin Descriptions. Full specifications can be found online.

Description
The TRBLU23 Bluetooth® Intelligent Serial Module is specifically designed for applications where robust short range connectivity is required. This particular module provides a reliable Bluetooth connection that exceeds all requirements in terms of performance. The excellent range of up to 300 meters with very low power consumption of less than 36 mA makes this module a true class leader.

Qualified Bluetooth 2.0 module supports data transfer rates up to 300 kbps and features an integrated antenna. Measures only 25.0 mm x 35.0 mm x 7.6 mm and weighs 8 grams.

As well as incorporating a fully approved embedded Bluetooth protocol stack, the module includes a comprehensive AT style interface that dramatically reduces the development time of applications from months to days.

Specifications
Manufacturer: Laird Connectivity
Manufacturer Part Number: TRBLU23-00200
Bluetooth®: Class 1
Frequency: 2.402 – 2.480 GHz
Max Transmit Power: +6 dBm (internal antenna)
Min Transmit Powe:r -27 dBm
Low Power Sniff: 2.5 mA typical
Receive Sensitivity: Better than -84dB
Range: 300m (free space)
Serial Interface: 3.3 V UART
GPIO: 9 x digital GPIO
Serial Parameters: Default: 9600,n,8,1
From 1200 bps to 921.6 kbps
DTR, DRS, RTS, CTS, DCD, RI DCE or DTE mode
Current Consumption: Idle mode = 13mA;Connected as master = 20mA
Physical Size: 25.0 x 35.0 x 7.6 mm, 8 g
Antenna: Internal – Multilayer Ceramic
Bluetooth: Qualified Bluetooth 2.0
Lead Free: RoHS Compliant
Temperature Range: -40˚C to +85˚C
Interface Levels: 3.3 V
Audio: Supported
Multipoint: Supported
Field Upgrades: Over UART
ADC: 2 x 8bit
Protocols: UART, AT command set, Multipoint
Data Transfer Rate: Up to 300 kbps
Packaging: Anti-Static Bag (Factory)

Key Features
■ Best-in-class range provides open field connectivity in excess of 300 meters
■ Integrated high-performance ceramic antenna
■ Adaptive frequency hopping to cope with interference from other wireless products
■ Optimised receive sensitivity to provide long range initial connections that largely eliminate connection hysterisis
■ A full industrial operating temperature range of -40°C to +85°C
■ Data transfer rate up to 300 kbps
■ Fully approved product Class 1 version 2.0 Bluetooth
■ Receive sensitivity better than -84 dBm
■ Support for 128 bit encryption
■ Non-discoverable modes
■ 40 way Hirose connector
■ 2 X 8 bit ADCs
■ 9 X GPIO
■ Low power modes
■ Lead free
■ Supports Wi-Fi co-existence
■ Embedded Bluetooth stack
■ Integrated antenna with up to 300m range
